GRACOHusky 15120
GRACO 654542
Model / order number
654542GRACO 654542 is a Husky 15120 air-operated double-diaphragm pump. Body material: PVDF. Fluid connection: 1.5 Female Center Flange ANSI/DIN in / 38 Female Center Flange ANSI/DIN mm.
- Nominal port size
- 1.5 F in / 38 F mm
- Maximum flow
- 454.25 L/min
- Wetted housing
- PVDF
- Diaphragm material
- PO
THE CONFIGURATION
Know the pump.
Product overview
GRACO 654542 is a Husky 15120 air-operated double-diaphragm pump.
- Body material: PVDF.
- Fluid connection: 1.5 Female Center Flange ANSI/DIN in / 38 Female Center Flange ANSI/DIN mm.
- Diaphragm: PO.
- Catalog maximum flow: 454.25 L/min.
- Maximum fluid pressure: 8.6 bar.
Selection and quotation
Quote model 654542 when requesting a configuration check. Confirm material compatibility, fluid temperature, required flow and discharge pressure for the intended duty.
TECHNICAL DATA
Specifications at a glance.
Review materials, connections and operating limits for your duty point.
Identification
| Brand | GRACO |
|---|---|
| Model / order number | 654542 |
| Series | Husky 15120 |
| Nominal port size | 1.5 F in / 38 F mm |
| Maximum flow | 454.25 L/min |
| Wetted housing | PVDF |
| Diaphragm material | PO |
| Drive type | Air-operated |
| Working pressure | 8.6 bar |
| Connection standard | 1.5 Female Center Flange ANSI/DIN in / 38 Female Center Flange ANSI/DIN mm |
| Check ball material | PTFE |
| Valve seat material | SS |
Performance
| Maximum flow | 120 gpm / 454.25 lpm |
|---|---|
| Maximum operating temperature (°F) | 225 |
| Minimum operating temperature (°F) | 32 |
| Minimum storage temperature (°F) | 32 |
| Maximum fluid pressure (MPa) | 0.86 |
| Maximum fluid pressure (psi) | 125 |
| Ordering configuration | Husky™ 15120 PVDF Pump, PP Center Section, SS Seats, PTFE Balls & PO Diaphragm |
| Maximum flow (L/min) | 454.25 |
| Maximum pressure (bar) | 8.6 |
Materials & construction
| Wetted material | PVDF |
|---|---|
| Ball material | PTFE |
| Body material | PVDF |
| Non-wetted material | Polypropylene (PP) |
| Manifold O-ring material | PTFE |
| Seat material | SS |
Connections
| Fluid inlet | 1.5 Female Center Flange ANSI/DIN in / 38 Female Center Flange ANSI/DIN mm |
|---|---|
| Fluid outlet | 1.5 F in / 38 F mm |
| Fluid port size | 1.5 F in / 38 F mm |
| Connection | 1.5 Female Center Flange ANSI/DIN in / 38 Female Center Flange ANSI/DIN mm |
Additional specifications
| Model | 654542 |
|---|---|
| Maximum solid size | 0.25 in / 6 mm |
| Air exhaust size (in) | 1 |
| Air exhaust thread gender | Female |
| Air exhaust thread standard | NPT |
| Maximum cycle rate (cycles/min) | 183 |
| Drive | Air-operated |
| Pump type | Air-operated double-diaphragm pump |
| Maximum working pressure (bar) | 8.6 |
| Maximum solids (mm) | 6 |
| Temperature range | 32 to 225 °F |
Maximum flow and maximum pressure are separate ratings; they do not describe one simultaneous operating point.
